Series 15 Hydraulic - Industrial Winch - 15000 lb - Anti Clockwise Rotation

PART NUMBER 65931

  • $ 2,130.76

Call for Availability
1 (800) 374-8028


  • For tow, utility and trailer applications
  • 6.0 cubic-inch motor provides pulling capacity up to 15,000 lbf.
  • Hardened steel two-stage planetary geartrain with 36:1 reduction provides fast line speed
  • Heavy-duty disc brake for dependable operation and plenty of holding power
  • Meets SAE J706 and CE standards
  • Wire rope, roller fairlead, and tensioner sold separately



15 HYD SPECS/PART NUMBERS
Part Number: 65931
Rated Pulling Force: 15000 lbf (6804 kgf)
Drum Barrel Diameter: 4.00 in (102 mm)
Drum Flange Diameter: 8.24 in (209 mm)
Distance Between Flanges: 9.95 in (253 mm)
Recommended Maximum Wire Rope Diameter: 1/2 in (12.7 mm)
Recommended Minimum Wire Rope Breaking Strength: 26600 lbf (12066 kgf)
Approximate Shipping Weight: 83.0 lb (37.6 kg)
Duty Cycle (intermittent per SAE J706 section 6.2): 932 ft (284 m)
Mounting Bolt Torque: 35 - 40 ft*lbf (47 - 54 N*m)
Maximum Layers of Wire Rope: 3 (with 1/2" dia. rope)
Gear Reduction: 36:1
Brake Type: Disk
Contactor / Remote Type: N/A
Standards Compliance:
SAE J706
CE Machinery Directive 98/37/EC and 2006/42/EC
ACCESSORIES
Wire Rope Tension Plate 10'': PN 31149
Fairlead Black 10'': PN 24336
Fairlead Chrome 10": PN 30859
Remote Clutch Mechanical: PN 38316
Remote Clutch Air: PN 71370
Wire Rope Assembly 1/2''x75' EIPS: PN 77534

PERFORMANCE DATA BY LAYER - 1/2" (12.7 mm) dia. rope
Drum Line Load * Line Speed 10 GPM Line Speed 15 GPM Drum Capacity
Layer lbf kgf kN ft/min m/min ft/min m/min ft m
1 15000 6804 66.7 12.8 3.9 18.9 5.8 21 6.4
2 12273 5567 54.6 15.6 4.8 23.1 7.0 46 14.0
3 10385 4711 46.2 18.5 5.6 27.3 8.3 75 22.9

* Never exceed the Rated Pulling Force. Installation of a Rated Capacity Limiter is recommended.


FIRST LAYER PERFORMANCE
Line Load Pressure Drop at 10 GPM Pressure Drop at 15 GPM Duty Cycle
lbf kgf psi BAR psi BAR min/10min
0 0 218 15.0 362 25.0 N/A
3000 1361 547 37.7 664 45.8 N/A
6000 2722 904 62.3 1003 69.2 N/A
9000 4082 1279 88.2 1379 95.1 N/A
12000 5443 1672 115.3 1790 123.4 N/A
15000 6804 2150 148.2 2200 151.7 N/A



Series 15 HYD Product Datasheet
