1500 AC - Winch - 1500 lbs./680 kg - 0.8 HP - 120V AC - Permanent Magnet Motor - 43 ft. Wire Rope

PART NUMBER 85330

  • $ 504.38

Call for Availability
1 (800) 374-8028


WARN 1500AC Utility Winch

The WARN 1500AC Utility Winch has the ability to deliver up to 1500 lbs or 680 kg of pulling power with an 0.8 HP engine and a 120V AC power battery. You will also find a lengthy 43 feet of durable, 3/16' diameter wire rope ready to work, as well as giving you a wide reach. The WARN 1500 AC winch is constructed of all metal housing, as well as planetary gearing, to provide an unparalleled smooth and reliable operation.

The vented motor cap and externally serviceable brushes aid in providing top end cooling of the motor, an extended motor life, and a lengthy run time. Your WARN 1500 AC Utility Winch comes fully equipped with a 10 foot (3m) power cord, which may be implemented wherever you have access to a 120V AC outlet. The WARN 1500 AC Utility Winch Pendant Remote is extremely advanced and completely sealed, and its 10 foot (3m) lead allows for a maximum amount of flexibility.

1000AC Specs

Rated Line Pull:  1,500 lbs or 680 kg
Motor:  120V AC, 0.8 HP (600W) Permanent Magnet
Controls:  Pendant Remote
Gear Train:  Planetary, Differential Planetary
Gear Ratio:  261:1
Clutch (free spooling):  Pull & Turn
Brake:  Self Braking Transmission
Drum Diameter/Length:  2.0"/3.3" (52mm/84mm)
Kit Shipping Weight:  29.1 lbs (13.2 kgs)
Rope:  Galvanized Steel Wire, Ø 3/16" x 43' (Ø 4.8mm x 13.1 m)
Fairlead:  Roller
Power:  120V AC, GFCI
Duty Cycle:  Intermittent
Finish:  Steel Grey Powder Coat
Warranty:  One Year
Mounting Bolt Pattern:  3.1" x 2.5" (78.8mm x 63.5mm)
Mounting Bolt:  4 x 8 mm
Fairlead:  Hawse
Winch Dimensions:  15.42" L x 5.7" D x 6.73" H (39.2cm L x 14.5cm D x 17.1cm H)
Weight:  28 lbs (12.7 kgs)
